Raymond Mill


Product introduction:
The Raymond mill adopts domestic and foreign advanced structure of the same plants, its structure is getting perfect day by day. For low consumption, low investment, environmentfriendly , small occupation area, and more efficient than ball mill. The rollers oscillate outward to press the ring because of the centrifugal force and the shovel scoops up the materials, send to the middle between ring and roller to accomplish the grind. So if roller and ring are damaged, it will not affect the fineness of final products. Life of tear and wear parts will be long. he set’s airflow system is closely sealed up and circulated under condition of negative and positive pressure.

Usage:
The Raymond Mill is widely used in the field of metallurgy, building materials, chemical industry and mining to process powder. The series is used in grinding the non-flammable and non-explosive stuff which has the Moh’s hardness below 7, humidity less than 6%, such as gypsum, talc, calcite, limestone, marble, feldspar, barite, dolomite, granite, kaolin, bentonite, bauxite, iron ore etc., the final products change from 613 micron to 44 micron. Through the function of separator and blower, the Raymond Mill can meet different customers’ demand.

Working principle:
Firstly, raw material is crushed by jaw crusher to the size required, then the crushed materials are elevated into a hopper from which the material is transported through the electro-magnetic vibrating feeder, evenly and continuously into the grinding chamber for powder-processing. The rollers oscillate outward to press the ring because of the centrifugal force and the shovel scoops up the materials, send to the middle between ring and roller to accomplish the grinding.

Liming company is a professional manufacture of micro powder mill, suspension mill, straight centrifugal mill etc.

Technical Data:
Notice: Any change of Raymond Mill technical data shall not be advised additionally.

Raymond Mill PDF Download (1.93MB)
